Six-DOF Stabilized Flight Platform UAV

Main bodyWeight in air16kgVolume400mm x 400mm x 265mmStructureFrame typeWithstand pressure depth500mThrusters6 thrusters (4 horizontal, 2 vertical)Front camera & LightsResolution1920*1080Zoom4x optical zoomFocusingAuto-focusingFocal length2.8mm~12mmPitch range±60°Lights4 headlights 2*3500LM; Small light 2*1500LMWire and cableLengthStandard 100mDiameter11.6mmWeight in waterZero buoyancySensorPortable equipmentSingle-beam sonar P360;multi-beam sonar M750D;side-scan sonar SS60 single-degree of freedom robotic arm G300;five-degree of freedom robotic arm RV5 multi-beam 1200ik;underwater = dimensional laser USL-100;
